Vascular Tufts of the Pupillary Margin
Christy M. Cunningham, MD, Nathaniel C. Sears, MD and Elliott H. Sohn, MD
Posted December 20, 2017
INITIAL PRESENTATION
Chief Complaint
Recurrent hyphema
History of Present Illness
A 68-year-old female presented to the retina clinic with a history of recurrent hyphema in both eyes (OU). She had multiple instances of spontaneous, non-traumatic hyphema for which she had eventually sought medical attention. She was seen by an outside ophthalmologist who had confirmed a hyphema was present and noticed vascular tufts on the pupillary margin. She was sent to our clinic to rule out any ischemic cause of the vascular tufts. She feels that heat and hot flashes contribute to her spontaneous hyphema events. Resting seems to allow for quicker resolution once a hyphema occurs.
Past Ocular History
Recurrent hyphema OU
Past Medical History
None
Medications
None
Allergies
NKDA
Family History
Non-contributory
Social History
Non-contributory
Review of Systems
Negative except for what is detailed in the history of present illness.
OCULAR EXAMINATION
Visual Acuity without correction (Snellen)
- Right eye (OD): Snellen: 20/20-2
- Left eye (OS): Snellen: 20/20-1
Ocular Motility/Alignment
- Full
Intraocular Pressure (IOP)by tonopen
- OD: 16 mmHg
- OS: 16 mmHg
Pupils
- OD: 4 mm in dark, 2 mm in light, no relative afferent pupillary defect (RAPD)
- OS: 4 mm in dark, 2 mm in light, no RAPD
Confrontation visual fields
Full to confrontation
External
Normal
Slit lamp exam
- Lids/lashes: Normal OU
- Conjunctiva/sclera: Normal OU
- Cornea: Normal OU
- Anterior chamber: No cell, no hyphema either eye
- Iris: Vascular tufts at the pupillary margin, 360 degrees scattered irregularly, no neovascularization of the iris, bilaterally. (See photograph below.)
- Lens: Trace nuclear sclerosis OU
Figure 1. Pupillary vascular tufts
Dilated fundus examination (DFE)
- Vitreous:Normal OU
- Disc: 0.2 cup to disc ratio, no neovascularization of the disc, either eye
- Macula: Flat OU
- Vessels: Unremarkable OU
- Periphery: Unremarkable, no ischemia or neovascularization noted, either eye
Differential Diagnosis
Vascular tufts of the pupillary margin versus neovascularization of the iris from ischemia such as ocular ischemic syndrome, vein occlusion, or diabetes. Neovascularization or blood in the angle of the eye are also included in the differential, including carotid-cavernous sinus fistulas, orbital varix, or Sturge-Weber syndrome.
CLINICAL COURSE
The glaucoma service was consulted. They had no further recommendations, as there was currently no evidence of optic nerve damage. They did note that there were no abnormal vessels in the angle. Argon laser therapy to ablate the vascular lesions was discussed and will be considered if the patient develops further hyphemas.
DIAGNOSIS
Vascular tufts of the pupillary margin
DISCUSSION
Spontaneous recurrent non-traumatic hyphemas can occur secondary to vascular tufts of the pupillary margin. The origin of these microhemangiomas is presumed to originate in the capillary network, which marks the end of the radial vessels and surrounds the sphincter of the iris [1]. Most patients with vascular tufts of the pupillary margin have no systemic disease, but they are also found in patients with diabetes mellitus and myotonic dystrophy [2].
Argon laser treatment of symptomatic iris vascular tufts promotes resolution of recurrent, spontaneous hyphema and may also be considered to mitigate the risk of hemorrhage from these lesions during subsequent intraocular surgery [3]. While there are not exact protocols for treatment of the vascular tufts, there are several circumstances when treatment would be appropriate. There have been several case reports depicting the setting when Argon laser was used to ablate the vascular tufts.
One case report described a woman who underwent Argon laser therapy to the lesions as she developed raised intraocular pressure from a hyphema. In this case report, the patient had no re-bleeding one year after laser therapy and fluorescein angiography showed reduced fluorescence [4]. Another case report described a 60-year-old woman who was treated with Argon laser following a hyphema. She subsequently developed fresh vascular anomalies three months later in different locations. Further treatment led to permanent obliteration [1]. Finally, a woman in her 70s presenting with a spontaneous left eye hyphema and was followed over two years. During this period of time, the vascular tufts enlarged with increasing hyperfluoresence confirmed on indocyanine green angiogram, but there was no hyphema recurrence or intraocular pressure elevation. Therefore, the patient was observed. The authors cited that typically Argon laser treatment is reserved for cases complicated by a recurrent hyphema [5].
Despite the unique appearance, prior to the diagnosis of vascular tufts of the pupillary margin, evaluation must be carefully undertaken to determine if there is an underlying cause of neovascularization. Careful fundus examination with consideration of wide-field fluorescein angiography or optical coherence tomography angiography, if available, are useful to determine whether there is any evidence of retinal non-perfusion which would prompt a more thorough systemic vascular work-up. One should also exclude conditions that may cause elevated episcleral venous pressure such as carotid-cavernous sinus fistulas, orbital varix, or Sturge-Weber syndrome, which can present with blood in the angle, visible by gonioscopy.
EPIDEMIOLOGY OR ETIOLOGY
|
SIGNS
|
SYMPTOMS
|
TREATMENT/MANAGEMENT
|
References
- Bandello F, Brancato R, Lattanzio R, Maestranzi G. Laser treatment of iris vascular tufts. Ophthalmologica. 1993;206:187-191.
- Coleman SL, Green WR, Patz A. Vascular tufts of pupillary margin of iris. American journal of ophthalmology. 1977 Jun 1;83(6):881-3.
- Strauss EC, Aldave AJ, Spencer WH, Branco BC, Barsness DA, Calman AF, Margolis TP. Management of prominent iris vascular tufts causing recurrent spontaneous hyphema. Cornea. 2005 Mar 1;24(2):224-6.
- Goyal S, Foster PJ, Siriwardena D. Iris vascular tuft causing recurrent hyphema and raised IOP: a new indication for laser photocoagulation, angiographic follow-up, and review of laser outcomes. Journal of glaucoma. 2009 Dec;19(5):336-8.
- Papastefanou VP, Burris CK, Sagoo MS. Iris vascular tufts. JAMA ophthalmology. 2016 Dec 1;134(12):e162755.
